Technical Data | WME2 | WME3 | |||||
Measuring Unit | Digital | Digital | |||||
Blades | |||||||
Max. blade weight | [kg] | 40 | 140 | ||||
Max. additional mass of blade adapter | [kg] | 20 | 60 | ||||
Max. blade moment | [kgm] | unlimited | unlimited | ||||
Machine | |||||||
Measuring time | [s] | 2-5 | 2-5 | ||||
Overload protection | 5x max. load | 5x max. load | |||||
weighing accuracy | [g] | 0.1 | 0.5 | ||||
Accuracy of internal unbalance measurement | [gmm] | 20 | 100 | ||||
Accuracy of the measured blade moment | [gmm] | <500 1) | <1500 2) | ||||
Power supply | [V] | 230 | 230 | ||||
Options | |||||||
Blade distribution software | BLADIS Net | BLADIS Net | |||||
1) Without adapter error. Calculated for a blade with 20 kg mass and an axis of rotation of the centre of gravity of the blade of 1500 mm. Blades with a smaller rotational radius will be measured more accurately | |||||||
2) Without adapter error. Calculated for a blade with 100 kg mass and an axis of rotation of the centre of gravity of the blade of 2000 mm. Blades with a smaller rotational radius will be measured more accurately | |||||||
